Homag 4086050463 Beckhoff Kl2408 8-Channel Digital Output Bus Terminal Module

1. High-density design

With 8 channels, it can achieve multiple digital outputs in a compact space, saving control cabinet space and suitable for applications with space requirements.

2. Electrical isolation

 Provides 500Vrms electrical isolation, separating the K-line from the field potential to avoid signal interference or equipment damage by ground potential differences, enhancing the safety and stability of the system.

3. Multiple protection functions

Equipped with reverse polarity connection protection, overcurrent protection, and short circuit protection functions, it can reduce the risk of equipment damage to incorrect connection or abnormal load, and extend the service life of the module.

4、 Real-time monitoring

Each channel has an independent LED indicator light, and the status of the indicator light (always on, off, flashing) canuitively determine whether the channel has a source, no source, or has a fault, which is convenient for quick troubleshooting and maintenance.

5、Voltage range

 The nominal voltage is 24V DC, with a voltage range of -15%/ 20%, which can to a certain range of voltage fluctuations to ensure the normal operation of the module.

1. Mechanical manufacturing

It can be used to control actuators such as cylinders and solenoid valves. For example, the welding production line in an parts factory can achieve millisecond-level synchronized actions through the EtherCAT bus, improving the accuracy of welding and production efficiency.

2. Energy management

 suitable for controlling devices such as inverters, switches, circuit breakers, etc., such as remote opening and closing operations through KBUS bus in photovoltaic power stations, with wide temperature design for outdoor use, and short-circuit protection function to prevent equipment damage due to overload

3、Smart building

can integrate access control system of electric lock control, relay driving of lighting system, etc., and upload data to the cloud using O UA protocol to achieve energy consumption optimization and remote operation and maintenance, and the compact design also saves control cabinet space.

4、Railway transportation

It can be used to control door opening and closing, braking system, etc., such as the metro train adopts this module achieve high availability transmission through redundant KBUS bus, which meets EN 50155 railway standard, and its anti-vibration performance adapts to the vehicle environment

5、Robot and automated production line

In the robot control system, KL2408 can ensure fast and reliable digital signal switching, achieving precise control equipment such as robotic end effectors, and improving the automation degree and efficiency of production.

1. Functional overview

 The KL2408 digital output terminal module connects binary control signals from the automation unit to the actuator in the process level electrical isolation, effectively avoiding signal interference and ensuring stable system operation.

2. Technical parameters

 Rated load voltage of 24V DC (-15%/ 20%), maximum output current of 0.5 per channel, total current 3A, with short-circuit protection function, short-circuit current less than 2A. Power contact current consumption of 60, K-bus current consumption of 18mA, electrical isolation of 500Vrms (K-bus/field potential).

3. Mechanical characteristics

The module adopts a compact design with dimensions of 12mm x 100mm x 68mm, weighs about70g, can be installed on a 35mm DIN rail, and has a protection level of IP20.

4、Protection and Indication

With reverse polarity connection protection, overload protection and short circuit protection functions, each channel has an independent LED indicator light, which can intuitively display the signal status of the channel, facilitating quick troubleshooting and maintenance.

5. Environmental adaptability

The working temperature range is 0… 55°C, the storage temperature range is -25… 8°C, the relative humidity is 95% (without condensation), the anti-vibration/anti-impact performance meets the EN 0068-26/EN 60068-2-27/29 standard, the anti-electromagnetic interference/anti-electromagnetic radiation performance meets the EN 1000-6-2/EN 61000-6-4 standard, and it can adapt to a variety of industrial environments.
