Wrapping Machine PLC

1. High-Speed Processing Performance

Faster Execution Speed:

Basic instruction execution time: 0.065μs (~3x faster than FX2N), ideal for high-speed logic control.

Enhanced floating-point arithmetic for complex calculations (e.g., PID control, data processing).

High-Speed Counting/Pulse Output:

Built-in 6 high-speed counters (single-phase 100kHz, dual-phase 50kHz).

Supports 3-axis independent pulse output (up to 100kHz), directly controlling stepper/servo motors (e.g., MR-J3/J4 servos).

2. Powerful Expandability

Modular Design:

Supports up to 8 expansion modules (compatible with FX2N series), max I/O points: 256.

Wide range of expansion modules:

Digital I/O (FX2N-16EX/EYR).

Analog I/O (FX3U-4AD/4DA, temperature module FX3U-4PT-PT100).

Communication modules (FX3U-485ADP, FX3U-ENET-L Ethernet).

Special Function Modules:

Positioning control (FX3U-20SSC-H, supports SSCNET III bus).

High-speed I/O (FX3U-16ET/ES).

3. Flexible Communication Capabilities

Built-in Communication Ports:

RS422/RS485 (supports Modbus RTU for HMI, inverters, etc.).

USB Programming Port (easy program download and monitoring).

Expansion Communication Modules:

Ethernet (FX3U-ENET-L, supports TCP/IP, FTP).

CC-Link (FX3U-64CCL, for distributed I/O control).

Profibus-DP (FX3U-232ADP, compatible with Siemens devices).

4. High Reliability & Stability

Industrial-Grade Design:

Operating temperature: -20°C to 60°C, strong resistance to vibration/interference.

Built-in watchdog timer (WDT) to prevent program crashes.

Data Backup:

Built-in flash memory (no battery required for program storage).

Optional battery (FX3U-32BL) for data backup.

5. Easy Programming & Debugging

GX Works2 Programming Software:

Supports Ladder Logic (LD), Instruction List (IL), Structured Text (ST).

Built-in simulation function for offline debugging.

Rich Instruction Set:

Over 300 application instructions, including PID control, data operations, string processing.

Supports subroutine calls and function blocks (FB) for code reuse.

6. Cost-Effectiveness & Compatibility

Affordable Price:

More budget-friendly than FX5U, suitable for cost-sensitive projects.

Backward Compatibility with FX2N:

Directly supports FX2N expansion modules (e.g., FX2N-16EX, FX2N-4AD), reducing upgrade costs.

High performance, high reliability, and flexible scalability have a wide range of applications in the field of industrial automation

Our PLC programmable controller, with its unique features, has great applications in industrial machinery control, motion control, process control, transportation and logistics, construction and infrastructure, energy and environmental protection, testing and inspection equipment

Equipment case: timed control of food and beverage filling machine

In the fiercely competitive woodworking manufacturing industry, this series is particularly suitable for users who need to balance performance and cost. It has a large inventory in industries such as machine tools, packaging, and electronic equipment, and has strong maintenance convenience. It is a very superior low-cost small equipment.
