Shangyin/Hiwin Linear Guide Slider Silent Guideway Cg Series-CGW20CC

1.Compact Structure with Powerful Space Adaptability: Employs an ingeniously miniaturized design, optimizing critical dimensions like slider width and height. It seamlessly fits into the narrowest installation spaces within equipment, excelling in precision transmission scenarios demanding exceptional structural compactness—such as small automated machinery and micro-robots—delivering stable linear guidance even within the most confined areas.

2. High Rigidity Bearing for Unwavering Operation: Features a robust reinforced raceway architecture and premium material selection, boasting outstanding radial and axial load-bearing capacity. This effectively withstands operational load impacts while minimizing deformation. Even during continuous duty cycles, it consistently maintains transmission accuracy and stability, reliably meeting the long-term demands of small to medium-load equipment.

3. Precision Guidance for Exact Positioning: The meticulously matched guide rail and slider surfaces undergo precision grinding, with clearance rigorously controlled. Achieving a high-grade industry positioning accuracy standard, it exhibits minimal parallelism error during motion. This fulfills stringent positioning requirements essential for electronic component assembly and precision testing, guaranteeing the accuracy of equipment processing or test outcomes.

4.Ultra-Low Resistance, Whisper-Quiet Operation, and Superior Energy Efficiency: Constructed with high-precision balls and a dedicated lubrication system, the balls exhibit minimal rolling resistance and an exceptionally low operating friction coefficient. This significantly reduces equipment power consumption, enhances energy utilization efficiency, and effectively controls operational noise, cultivating an exceptionally quiet working environment ideal for noise-sensitive applications like laboratory equipment and medical instruments.

5. Reinforced Protection for Enhanced Durability: The slider surface benefits from professional protective treatment, coupled with an integrated sealed structure design. Its standard protection level confidently handles common harsh environments—including dust and light liquid splashes—reducing internal component wear caused by contaminant ingress. Core components utilize wear-resistant materials, extending product service life and minimizing equipment maintenance frequency and associated costs.

6.Flexible Adaptation with Broad Versatility: Effortlessly pairs with guide rails of varying specifications within the same series. Compatible with diverse driving mechanisms, it readily adapts to transmission needs across multiple fields—including small CNC machine tools, 3C product automated production lines, and precision instrument workbenches. Large-scale custom modifications are unnecessary, significantly reducing equipment design and assembly complexity.

3C Electronic Equipment Field：Suitable for assembly lines of consumer electronics such as mobile phones and computers, such as the mobile platform of PCB chip mounters and the transmission mechanism of display module assembly machines. Its compact size (38mm width, 24mm height) can fit into the narrow internal space of equipment. The C3-level positioning accuracy and parallelism of ≤0.025mm/1000mm can ensure precise alignment of electronic components, meeting the high-precision assembly requirements of 3C products. Meanwhile, the IP54 protection level can cope with the dust environment in the workshop and reduce equipment failures.

 Small Precision Instrument Field：Applied to the sample conveying mechanism of laboratory analytical instruments (such as chromatographs and spectrometers) and the guiding components of small testing equipment (such as precision caliper calibrators). The low-friction operation characteristic (with SUJ2 bearing steel balls) can avoid the interference of vibration on test data. The applicable temperature range of -15~70℃ adapts to the environmental fluctuations in the laboratory, and the lightweight design (0.18kg single weight) can also reduce the overall load of the instrument and improve operation stability.

 Medical Equipment Field：Used in the transmission system of small medical equipment, such as the probe moving mechanism of portable ultrasonic diagnostic instruments and the fine-tuning components of dental treatment chairs. The slider body is made of 6063-T5 aluminum alloy with hard anodizing treatment, and its smooth surface has no impurity shedding, meeting the cleaning standards of medical equipment. The radial rated dynamic load of 15.2kN can support the stable movement of equipment components, and the low-noise operation characteristic can also improve the comfort of patients during use.

Automated Sorting Equipment Field：Suitable for the material pushing guide rails of small sorters in e-commerce and logistics industries (such as medicine and electronic component sorting equipment). The axial rated dynamic load of 4.6kN can meet the transmission needs of materials with small to medium weight. The chrome-plated guide rail (default) and IP54 protection can cope with slight dust and humidity in the sorting workshop. Combined with the quick installation design, it can improve equipment assembly efficiency and reduce later maintenance costs.

Office Automation Equipment Field：Used in the paper conveying and guiding mechanism of high-end printers and the toner cartridge moving components of copiers. The compact structure can fit into the narrow internal space of office equipment. Low friction and low noise operation can reduce equipment energy consumption and working noise, meeting the requirements of office environments for equipment mute and energy

New Energy Small Equipment Field：Applied to the electrode contact moving mechanism of small lithium battery testing equipment (such as cell voltage testing machines) and the cutting positioning guide rail of photovoltaic micro-components. The wear-resistant characteristic of the slider (SUJ2 balls + hard anodizing) can adapt to the high-frequency operation of the equipment. The stable guiding accuracy can ensure the accuracy of testing or cutting positions, meeting the reliability requirements of the new energy industry for equipment.

The CGW20CC slider is a precision-engineered rolling guide component, meticulously developed for demanding small-to-medium load linear transmission scenarios. Its compact footprint, exceptional guidance precision, and remarkable adaptability make it the ideal transmission solution for fields like 3C electronics, compact instrumentation, and medical devices. It effectively addresses critical equipment requirements for optimized space utilization, operational stability, and pinpoint accuracy.

Structurally, the slider embraces a miniaturized design philosophy. Its remarkably compact dimensions—just 38mm wide, 24mm high, and 65mm long—paired with standardized mounting holes (5.5mm diameter, 45mm center distance), enable effortless integration into the narrowest equipment spaces. This facilitates swift assembly without demanding complex modifications. Weighing a mere 0.18kg, its lightweight nature significantly reduces the overall system load, making it perfectly suited for weight-sensitive compact transmission systems. Material-wise, the slider body is crafted from robust 6063-T5 high-strength aluminum alloy. This material undergoes hard anodizing, achieving superior corrosion resistance and enhanced wear resistance. Complementing this, SUJ2 bearing steel balls and a specialized cage work in concert with a long-life lubrication structure. This synergy dramatically lowers the operating friction coefficient, minimizes component wear, and significantly extends the service life.

Performance-wise, the CGW20CC slider excels in accuracy and stability: it achieves a positioning accuracy of grade C3, maintains parallelism error ≤0.025mm/1000mm, and features a guide rail surface roughness ≤0.4μm. This ensures flawless high-precision linear guidance, meeting the exacting alignment demands of electronic component assembly and precision testing. Boasting a radial rated dynamic load of 15.2kN and an axial rated dynamic load of 4.6kN, it reliably withstands small-to-medium load impacts, guaranteeing consistent transmission reliability during continuous operation. Furthermore, the slider comes standard with an IP54 protection rating, effectively repelling dust and minor liquid splashes, ensuring adaptability across diverse environments like workshops and laboratories. Its operational temperature range spans -15~70℃, adeptly handling temperature fluctuations in various scenarios. Combined with its inherently low-noise operation—enhanced by the low-friction design—it fosters a quiet working environment. This further broadens its application boundaries, solidifying its role as the core transmission component for 3C electronic equipment, compact precision instruments, medical devices, automated sorting systems, compact new energy equipment, and office automation machinery.
