Rough Surfaces Spk Suction Plate Proximity Sensor

I. Product Advantages

1. 1.Highly Reliable Detection
   Operates on the inductive principle, specifically for detecting metal objects. Non-contact operation ensures no mechanical wear, resulting in an extremely long service life and stable performance in harsh industrial environments.

2.


3. 2.Easy Installation, Space-Saving
   Standard 10mm cylindrical housing (D10) for easy mounting. M12 connector (MS6, M12) simplifies wiring, allowing for quick plug-and-play connection and replacement.

4.


5. 3.High Switching Frequency
   Capable of detecting rapidly moving objects, meeting the requirements of high-speed automated production lines.

6.


7. 4.Rugged and Durable
   Typically features a high protection rating (e.g., IP67), providing resistance against dust ingress and temporary immersion in water, as well as resistance to oils and corrosion.

8.


9. 5.Strong Interference Immunity
   Incorporated shielded design prevents interference from adjacent sensors or surrounding metals, ensuring accurate and error-free detection.

10.


11. 6.LED Status Indication
    Built-in LED indicator provides visual feedback for power status and switching action, facilitating easy on-site commissioning and troubleshooting.

II. Product Features

1. 1.Operating Principle: Inductive

2.


3. 2.Sensing Range: 2mm (G2)

4.


5. 3.Housing Size: 10mm diameter cylindrical (D10)

6.


7. 4.Output Type: PNP, Normally Open (L, P1)

8.


9. 5.Connection Type: M12 connector (MS6, M12)

10.


11. 6.Supply Voltage: Typically 10-30V DC

12.


13. 7.Protection Rating: Typically IP67

14.


15. 8.Housing Material: Metal (e.g., nickel-plated brass) or Stainless Steel

1. 1.Machinery Manufacturing & Automation Equipment:

2. Used to detect cylinder piston positions, mold frame positioning, tool changer locations, and moving slide limits. It is a core sensor in CNC machines, machining centers, and automated assembly lines.

3.


4. 2.Material Handling & Packaging Systems:

5. Detects the presence of metal workpieces or pallets on conveyors and sorting machines for counting, positioning, and process control.

6.


7. 3.Automotive Manufacturing & Assembly Lines:

8.  Widely used in robotic welding and handling stations to check if clamps are closed or parts are in place, ensuring production cycle times and operational safety.

9.


10. 4.Material Handling (Cranes/Lifts):

11. Used for detecting upper limits on hooks and positioning translation carts to prevent equipment from over-traveling, ensuring safety.

12.


13. 5.Process Industries:

14.  In equipment with metal components within food, pharmaceutical, and chemical industries, it detects valve open/close status and gate positions. Its high protection rating allows it to adapt to humid and wash-down environments.

The SDE1-D10-G2-MS6-L-P1-M12 is a 10mm cylindrical inductive proximity sensor with a 2mm sensing range, featuring PNP normally open output and M12 connector connection. It detects metal objects without contact through electromagnetic induction, boasts an IP67 protection rating, and operates reliably in industrial environments from -25°C to +70°C. With its compact design for easy installation, it is suitable for automation applications such as position detection, counting, and limit control, offering high reliability and long service life.
